CYLINDER BLOCK AND CRANKCASE
Page 4B–32 90-857138R1 MAY 2000
2. Install the breather tubes and wave washers.
a
b
a-Breather Tube (2)
b-Wave Washer (2)
3. Install the breather cap.
a
b
c
a-Screw (2)
b-Breather Cap
c-Gasket
Breather Cap Screw Torque
70 lb-in. (8 Nm)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 6 SERIES and is the answer not in the manual?

Mercury 6 SERIES Specifications

General IconGeneral
StartingManual
Cylinders1
SteeringTiller
Horsepower6 HP
Full Throttle RPM Range5000 - 6000 RPM
Fuel TypeGasoline
