Mercury 60 FourStroke EFI Formula Race User Manual

FEATURES AND CONTROLS
27
Warning Light and Guardian
OFF
rob7
a
b
d
e
c
START ON
a - Ignition module
b - Lanyard stop switch cap
and stop switch
c - Ignition/warning light
d - Ignition switch
e - Start switch
When the ignition switch is toggled to the "ON" position, the
warning light will turn on for a moment as a test to ensure it is
working.
The Engine Guardian System monitors the critical sensors on the
engine for any early indications of problems. The system will
respond to a problem using the ignition/warning light and/or
reducing engine power in order to provide engine protection. Refer
to Overspeed Rev Limit for instructions on resetting the Engine
Guardian System.
Light Mode Problem Guardian Monitor Display
None
Warning Light
Failure
No Yes
Single Blink
Power Up/System
Check
No Yes
