Mercury 75 OptiMax User Manual

MAINTENANCE
76 eng
!
WARNING
Rotating propellers can cause serious injury or death. Never
operate the boat out of the water with a propeller installed.
Before installing or removing a propeller, place the drive unit in
neutral and engage the lanyard stop switch to prevent the
engine from starting. Place a block of wood between the
propeller blade and the anti‑ventilation plate.
1. Shift the outboard to the neutral ("N") position.
N
26838
IMPORTANT: Refer to Spark Plug Inspection and Replacement
for removing spark plug leads.
2. Remove the spark plug leads to prevent the engine from
starting.
26899
3. Straighten the bent tabs on the propeller nut retainer.
26900

Mercury 75 OptiMax Specifications

General

Engine Type	2-stroke
Displacement	1526 cc
Horsepower	75 hp
Alternator	60 amp / 756 watt
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-5750 rpm
Steering	Remote
Fuel Induction System	2-stage direct fuel injection
Shaft Length	20"
Weight	170 kg
