MAINTENANCE
78 eng
Tube
Ref No.
Description Where Used Part No.
95
2-4-C with
PTFE
Propeller shaft 92-802859A 1
NOTE: The Flo‑Torq lll propeller drive hubs are designed to
have a small amount of free play when installed. This free play
allows the propeller to slide back and forth on the rear thrust
hub (up to 3.17 mm [1/8 in.]) and rotate up to 10 degrees.
2. Flo‑Torq III drive hub propellers ‑ Install the forward thrust
hub, replaceable drive sleeve, propeller, thrust hub,
propeller nut retainer, and propeller nut onto the shaft.
a - Propeller nut
b - Propeller nut retainer
c - Rear thrust hub
d - Propeller
e - Replaceable drive sleeve
f - Forward thrust hub
3. Place a block of wood between the gearcase and propeller.
Torque the propeller nut to specification.
Description
Nm lb. in. lb. ft.
Propeller nut 75 55
