Mercury 80 Owner's Manual

FEATURES AND CONTROLS
29
AUXILIARY TILT SWITCH
This switch can be used to tilt the outboard up or down using the power trim system.
a
20886
a - Auxiliary tilt switch
SHALLOW WATER OPERATION
When operating your boat in shallow water, you can tilt the outboard beyond the maximum trim range to prevent
hitting bottom.
1. Reduce engine speed below 2000 RPM.
2. Tilt outboard up. Make sure all the water intake holes stay submerged at all times.
3. Operate the engine at slow speed only. If engine speed exceeds 2000 RPM, the outboard will
automatically return down to the maximum trim range.

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
