OUTBOARD INSTALLATION
66
2897
a
b
c
d
a - Special washer head bolt (10-856680)
b - Flat washers
c - Nylon insert locknut (11-826709113)
d - Nylon insert locknut (11-826709113)
Description Nm lb. in. lb. ft.
Special washer head bolt 27 20
Nylon insert locknut "d" 27 20
Nylon insert locknut "c" Tighten until it seats, then back off 1/4 turn
Assemble steering link rod to steering cable with two flat washers and nylon insert locknut. Tighten locknut until
it seats, then back nut off 1/4 turn.
Assemble steering link rod to engine with special washer head bolt and locknut. First torque special washer head
bolt, then torque locknut to specifications.

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
