Mercury 80 Owner's Manual

OUTBOARD INSTALLATION
79
a
d
b
c
20827
a - Throttle cable opening
b - Flat washer
c - Retainer clip
d - Cable barrel
7. Lock the cable in place with the cable latch.
20828
a
a - Cable latch
8. If the shift cable is already installed, place the high pressure fuel hose back into the hose retainers.
Reinstall the access cover.

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
