Mercury 9.9 User Manual

MAINTENANCE
eng 103
1. Remove the spark plug lead to prevent engine from starting.
26899
2. Move gear shift lever into neutral (N).
a - Reverse
b - Neutral
c - Forward
3. Straighten and remove cotter pin.
4. Place a block of wood between gearcase and propeller to
hold propeller and remove propeller nut.
5. Pull propeller straight off shaft. If propeller is seized to the
shaft and cannot be removed, have the propeller removed
by an authorized dealer.
IMPORTANT: To prevent the propeller hub from corroding and
seizing to the propeller shaft (especially in saltwater), always
apply a coat of the recommended lubricant to the entire
propeller shaft at the recommended maintenance intervals and
also each time the propeller is removed.
N
26838
c
a
b
28595

Mercury 9.9 Specifications

General

Cylinders	2
Fuel Tank	External
Full Throttle RPM Range	5000 - 6000 RPM
Fuel Induction System	Carbureted
Alternator Amp	6 amp
Horsepower	9.9 hp
Starting	Manual
Shaft Length	15 in, 20 in
Steering	Tiller
