ENGINE INSTALLATION
eng 133
2. Route the remote wiring harness through the rubber
grommet.
3. Open up the clamp in the bottom cowl and position the
remote wiring harness below the clamp. Connect the 8 pin
connector to the engine harness. Push the clamp down and
secure the remote wiring harness into the bottom cowl.
a - Clamp
b - Remote wiring harness
c - 8 pin connector
d - Rubber grommet
a
b
c
b
d
28798

Mercury 9.9 Specifications

General

Cylinders	2
Fuel Tank	External
Full Throttle RPM Range	5000 - 6000 RPM
Fuel Induction System	Carbureted
Alternator Amp	6 amp
Horsepower	9.9 hp
Starting	Manual
Shaft Length	15 in, 20 in
Steering	Tiller
