54
CD778
STERNDRIVE AND TRANSOM VIEWS
1
1
7
6
4
5
8
10
11
9
3
2
12
10
13
14
77769
1-Steering System
2-Transom Assembly
3-Sterndrive Unit
4-Antiventilation Plate
5-Power Trim Cylinder
6-Propeller
7-Seawater Intake Openings
8-Speedometer Pitot Tube
9-MerCathode Electrode (Optional)
10 - Inner Transom Plate
11 - Exhaust Pipe
12 - Rear Engine Mount
13 - Boat Transom / Hull
14 - Power Steering Cylinder (Optional)
