Mercury MerCruiser 5.0 TKS

Section 5 - Maintenance
90-899883179 OCTOBER 2007 Page 81
IMPORTANT: To ensure that the MerCathode reference electrode is not damaged, do not
paint or pressure wash.
6206
a
b
a - MerCathode controller b - MerCathode assembly
Anode Kit (if equipped) ‑ Mounted to the boat transom.
5642
Trim Cylinder Anodes ‑ Mounted on each trim cylinder.
a
5643
a - Trim cylinder anodes
