Section 2 - Getting to Know Your Power Package
90-899883173 DECEMBER 2007 Page 21
On the Velvet Drive 5000A and 5000V Transmissions the transmission identification plate
indicates gear ratio, serial number and model.
7370
a
Velvet Drive 5000A ‑ 8 degree down‑angle transmission shown (5000V ‑ V‑drive similar)
a - Transmission identification plate
ZF MARINE TRANSMISSIONS
On the ZF Marine 8 Degree Down‑Angle and V‑Drive Transmissions, the transmission
identification plate indicates gear ratio, serial number, and model.
a
7449
Typical ZF Marine down‑angle transmission shown (V‑drive similar)
a - Transmission identification plate
