Two 10 amp fuses protect the O
2
(oxygen) sensors. These are located at the rear of the
engine, near the 14‑pin connector.
Oxygen sensor fuses
A 15 amp accessory fuse protects the accessory circuits.
a - Fuse cover
b - 15 amp fuse
c - Power harness
A power harness, connected to the engine starting battery, minimizes voltage drop to the
electrical system. This harness is protected by a 5 amp fuse. This connection is located at
the rear of the engine, near the 14‑pin connector.
