PUMP
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 9A-13
INSTALLATION
1. Using hose clamp, install new hose on back of pump. Tighten clamp securely.
72848
a
b
a-Hose Clamp
b-Hose
2. Using hose clamp, install hose on fluid cooler. Tighten clamp securely.
75595
a
a-Hose
3. Fill and air bleed system. Refer to SECTION 1B “Maintenance” (see “Table of Con-
tents”).
