MAINTENANCE
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 1B-41
NOTE: Some models will have components arranged in a different order. All configurations
are not shown. Checking, replacing and adjustment procedures are the same.
75424
e
b
a
d
c
Inboard Model
a-Idler Pulley
b-Seawater Pump Pulley
c-Crankshaft Pulley
d-Circulating Pump Pulley
e-Alternator Pulley
75487
a
b
c
d
e
f
Sterndrive Model
a-Idler Pulley
b-Seawater Pump Pulley
c-Crankshaft Pulley
d-Circulating Pump Pulley
e-Alternator Pulley
f-Power Steering Pump
