SERVICE MANUAL NUMBER 23TROUBLE CODE DIAGNOSTICS - 454/502 MAG MPI & 8.2L MPI
Page 5F-36 90-861326--1 MARCH 1999
Code 43 (3 of 3): Knock Sensor (KS) Circuit (Scan)
STEP ACTION VALUE YES NO
PROCEED TO
1. Connect a test light to ground.
2. Disconnect KS module harness connector.
7
3. Touch the test light to KS module harness
connector terminal “B” (CKT439).
Is the test light on?
– Step 11 Step 12
8
Inspect knock sensor terminal contacts. If OK,
replace knock sensor.
– – –
9
Check for open or short in CKT 496. If OK, re-
place knock sensor.
– – –
10
CKT 496 open, shorted to ground or faulty
knock sensor module.
– – –
11
CKT 485 open, shorted to ground or faulty
knock sensor module.
– – –
12 Repair open or grounded CKT 439. – – –
13 Repair open ground CKT 486. – – –
14 Faulty ECM. – – –
