WALTER V-DRIVE TRANSMISSION
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 8E-7
5. Start engine and run it until it reaches normal operating temperature. Stop engine,
remove dipstick and check fluid level.
75192
a
a-Dipstick
6. Connect the propshaft coupling to the output shaft flange of the transmission. Torque
screws and nuts to 50 lb. ft. (68 N·m).
7. Check with a feeler gauge in at least four places (without rotating either flange) to ensure
that there is no more than a .003 inch (0.07 mm) gap between the flanges.
75646
