FUEL DELIVERY SYSTEM FOR ELECTRONIC FUEL INJECTION SERVICE MANUAL NUMBER 23
Page 5A-14 90-861326--1 MARCH 1999
4. Install the fuel rail fuel line following appropriate procedure:
Procedure A
1. Install fuel cooler-to-fuel rail line as follows:
a. Install two (of six) O-rings onto the cooler-to-fuel rail fuel line where it attaches to the
cooler, if not already present on the line.
b. Completely loosen, but do not remove, the stepped screw that retains the fuel line.
c. Lubricate the two fuel line O-rings with a small amount of liquid dish soap (obtain
locally).
d. Insert the fuel line into the cooler orifice. Hand tighten the special screw.
e. Torque the stepped screw to 81 lb. in. ( 9 N·m).
