MULTI-PORT FUEL INJECTION DISASSEMBLY AND REASSEMBLY

SERVICE MANUAL NUMBER 23

90-861326--1 MARCH 1999 Page 5C-25

INSTALLATION

1. Connect electrical connector to the Knock Sensor (KS) module.

2. Mount KS module to electrical bracket.

72801

Typical

a-Electrical Bracket

b-Knock Sensor (KS) Sensor
