INSTALLATION
90-888438 JUNE 2002 Page 1D-29
7. Connect fuel line to fuel inlet fitting, secure with U.S. Coast Guard approved hose clamp
(183.532).
8. Vapor separator tank (VST) must be vented to fuel tank (250 hp). Vent hose must comply
with U.S. Coast Guard/ABYC regulations.
59414
b
a
a-VST Vent Hose Fitting
b-Fuel Inlet Fitting
