43
MAINTENANCE
2-4
b
c
a
1-3
Checking Power Trim or Hydraulic Up/Down
Fluid
1
Place outboard in the full down (in) position.
2 Remove trim pump fill/vent screw (a)
• Wipe fill/vent screw with a clean, lint-free cloth and reinstall - DO
NOT THREAD INTO PUMP.
• Remove fill/vent screw and note oil level. Oil level must be be-
tween the “ADD” (c) and “FULL” (b) marks on dipstick.
• If necessary, add Quicksilver Power Trim & Steering Fluid or SAE
10W-30 or 10W-40 motor oil thru the fill/vent screw hole to bring
level up to the “FULL” mark on the dipstick. DO NOT OVERFILL.
3 To purge system of air, raise the outboard 2 or 3 times. Recheck
oil level and add oil if necessary.
4 Reinstall fill/vent screw by turning it all-the-way in, then back it out
one and a half (1-1/2) turns.
CAUTION
Fill/Vent screw MUST BE backed out one and a half (1-1/2)
turns (after bottoming out) to vent pump reservoir.
FAILURE
TO BACK SCREW OUT COULD RESULT IN DAMAGE TO
PUMP.
