Section 4 - Setup and Calibrations
90-8M0074777 eng MAY 2013 Page 31
SmartCraft
Trim >
Location: port, port center,
starboard center, starboard >
Has trim
Turn on (check
mark) or off (no
checkmark)
—
Calibration >
Set trim in,
maximum trim
range, full trim out,
reset, restore, save
—
Tabs >
Tab source >
None, PCM0,
PCM1, PCM2,
PCM3, TVM
— —
Starboard and port calibration
Number of
calibration points (2
or 3),
Set tab down, mid,
up range, reset,
restore, save
—
Smart contextual >
Enable
Turn on (check
mark) or off (no
checkmark)
— —
Engine running threshold > Set limit — —
Slow demand threshold > Set limit 0–99 % — —
Fast demand threshold > Set limit 0–99 % — —
Lever shift threshold > Set limit 0–99 % — —
Mode timer threshold >
Set limit 0–10.0
seconds
— —
Mode stable threshold >
Set limit 0–10.0
seconds
— —
Steady state threshold >
Set RPMs per
second
— —
Limits >
RPM, fuel rate, coolant temp,
oil temp, oil pressure, water
pressure, battery voltage,
intake temp, boost pressure,
transmission oil pressure and
temperature >
Set the limits:
minimum,
maximum, warning
low, warning high,
reset, save for
each engine.
— —
Supported data >
Location: port, port center,
starboard center, starboard >
Actual gear, boost
pressure, fuel
pressure, gear
pressure, gear
temperature, load
percent, manifold
temperature, MIL
(malfunction
indicator lamp), oil
pressure, oil
temperature,
throttle present,
water pressure
Turn on (check
mark) or off (no
checkmark)
—
Advanced > Number SmartCraft network >
1 or 2
Used with vessels
with more than 1
SmartCraft network
— —
Network number >
A or B
Used to identify the
network
— —
