Mercusys MB110-4G User Manual

03
Chapter 1
Introduction
1. 2. 2. Rear and Bottom Panels
The following items are located on the rear and bottom panels.
Item Description
4G/3G External Antenna
Ports
Connect external antennas (if any) to strengthen the LTE network.
WPS/RESET Button
Press and hold this button for more than 5 seconds to reset the router.
Press for 1 second to use the WPS function.
Ethernet Port 1 LAN port only. Used to connect a local device.
Ethernet Port 2
LAN/WAN port.
By default, this port is used as the LAN port to connect a local device.
When the router is set to Wireless Router mode, it can be used as the WAN
port to connect the DSL/cable Modem or Ethernet outlet. To change to this
mode, refer to Set Up the Router in Wireless Router Mode.
POWER Socket
Connect the power adapter. Please use the power adapter provided with
this router.
Nano SIM Card Slot Insert the nano SIM card.

Mercusys MB110-4G Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA, HSPA+, UMTS
SIM card type	NanoSIM
4G bands supported	700, 800, 850, 900, 1800, 2100, 2300, 2500, 2600 MHz
UMTS bands supported	850, 900, 2100 MHz
Mobile network generation	4G
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Desktop/pole router
Product color	White
Antenna type	2x2
Output current	0.85 A
Output voltage	9 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	92 mm
Width	90 mm
Height	150.5 mm
