34
Configuring the DSP
loudspeakers
Choosing standard settings
The DSP loudspeakers provide the following five
alternative standard settings, called Types, which
configure all aspects of the DSP loudspeakers into the
most commonly needed configurations:
Type Description
1 Standard setting for 2-channel system.
5 For use with a Meridian CD player (eg 808.2)
connected to the RJ45 SpeakerLink input; all
other sources use the co-axial input.
6 For use with a Meridian Surround Controller.
7 For use in a second room.
8 For use in the second or third room of a three-
room system.
Types 2, 3, and 4 are for compatibility with 200/600
series units.
In all cases except Type 5, the D1 input is used for all
sources.
Choosing one of the standard settings overrides any
other configuration you may have performed, and so
can be used to reset the configuration of the speakers.
To select a standard setting
Switch off the DSP loudspeaker.
Turn on the power again while holding down the
number key on the remote which corresponds to the
Type you want to use.
The display will show the Type number.
For example:
Type1
•
•
Release the remote key.
The display will show:
L.M.RJ45
You should now specify the speaker’s position as
follows.
To specify the speaker position
Press A or V to specify the speaker position.
The options are shown in the following table:
Display Position
L. Left.
R. Right.
C. Centre (Type 6 only).
To choose master or slave and the
primary connector
You should select one loudspeaker to be the master;
this will normally be the centre channel. For more
information see
Connecting to other equipment
, page
21. Each other DSP loudspeaker should be configured
as a slave.
Press the green > (Play) key on the remote.
For each speaker this steps between the following
four options:
Option Master/slave Primary input
M.RJ45 Master Meridian RJ45
SpeakerLink
M.Coax Master Digital co-axial
S.RJ45 Slave Meridian RJ45
SpeakerLink
S.Coax Slave Digital co-axial
•
•
•
•
