12
Installing the EVO Wall
The CleanTech
®
EVO Wall connects easily to your existing hot and cold-water lines using standard ½" MNPT (faucet) style fittings. These fittings were chosen because
they are commonly available, very reliable and can be disconnected quickly. You will also need a grounded 120V electrical outlet, and a standard 1 ½” drain line.
If these hook-ups are not readily available, you will need to consult with your commercial plumber or electrician. Because of the different building codes and licensing
regulations, Meritech cannot accept responsibility for providing plumbing and electrical modifications to your facility. However, a Meritech installation specialist will be
happy to provide the necessary guidance to ensure a correct installation.
Follow the instructions in the installation instructions below guide of this manual for further installation information.
Installation Instructions
1. Place top of the wall mount bracket facing up on wall at desired height and location. Recommended height is 42” from finished floor to top of wall mounting
bracket, however top of wall mount bracket must be a minimum of 18” above the wall drain. Trace the 6-hole locations from the wall mount bracket onto wall.
2. Install the wall mount bracket with fasteners compatible with wall construction at the 6 traced hole locations. Fasteners length and material should be such that
fastener can support a 200-pound vertical force each.
3. Hang the EVO Wall onto the wall mount brackets “Hooks”. Verify the system is level and securely attached to the wall.
4. Hook up hot/cold supplies and drain lines. Do not hard pipe to water inlets of the system – Use flexible hoses supplied with system. Plug in power cord. Install
solution cartridges per the instructions within this manual or instructions on station. P-Trap to be supplied by customer.
5. Turn water on and inspect for leaks. Repair as necessary
Unpacking & Installing this EVO Station
Unpacking the EVO Station
To unpack your EVO Wall carefully following the instructions depicted on the sides of the box. Be careful
when cutting tape and opening packaging to prevent damage of inside components. For additional
information on how to unpack your CleanTech station, reach out to the Meritech support team at 1 (800) 932-7707.
Important Information:
Codes varies from municipality to
municipality, Meritech has designed in the
devices listed above to meet most
jurisdictions. Conformity and compliance to
local and national plumbing / health
departments regulations regarding backflow
prevention is the responsibility of the installer.
