4 Prepare Parts for Assembly
11
Meritor Maintenance Manual MM-0637 (Revised 07-12)
Figure 4.2
Figure 4.3
Figure 4.4
Figure 4.5
6. Observe the following guidelines when servicing the bearings.
앫 Do not clean bearing cones. Replace them.
앫 Use the same type fluid or grease from the original
equipment manufacturer.
앫 Replace with half tolerance bearings provided by the
original equipment manufacturer.
7. Use a press to install the bearing cup into the hub. Verify that
the cup is fully pressed against the seat. Do not over press.
Figure 4.6.
Figure 4.6
Figure 4.2
Figure 4.3
Figure 4.4
1003020a
ETCHING AND PITTING
Figure 4.5
Figure 4.6
1003021b
SPALLING AND FLAKING
4005742a
