Merlin RollerAce MR60 - Special Features; Accessories

12
Motion detecting control panel
• Connect white/red wire to the red “wired wall control”
quick connect terminal and the white wire to the
white quick “wired wall control” connect terminal.
T
he Protector System™ (IR Beams)
• Connect both white wires to the white “safety beam”
quick connect terminal and both white/black wires to
the grey “safety beam” quick connect terminal.
NOTE: Full instruction are supplied with these
accessories.
1
9
S
PECIAL FEATURES - OPTIONAL
(1) Model CM844 4 Channel transmitter
(2) Model CM128 Wireless wall button
(3) Model C940 Single channel transmitter
(4) Model C943 3 Channel transmitter
(5) Model C945 3 Channel mini transmitter
(6) Model 75LM Illuminated door bell push button
(7) Model C98 Motion detecting control panel
(8) Model C840 Keyless entry system
(9)Model C77 The Protector System
TM
(10) Model CM1702 Quick release lock
(11) Model 760E Outside keyswitch
(12) Model C379 Wireless fingerprint access system
22
5
3
7
1
11
2
L
O
C
K
L
I
G
H
T
4
C840
CM128
C98
760E
CM1702
C77
C940 C943
C945
8
9
10
CM844
ENROLL
F
AIL
RETRY
SEND
P
ASS
READY
ENROLL
C379
75LM
6
ACCESSORIES
