MERLYN 6 Series Installation Instructions

Tools Required
- 6mm and 7mm masonry drill bit
- Power drill
- Quality Silicone
- Pencil
- Tape Measure
- #2 Philips Head screw driver
- Spirit level with horizontal and vertical level indicators
IMPORTANT - Installation site
1. Ensure the top surface of the shower tray on which the enclosure will be installed is level in every direction.
2. The tiles or other wall finishing should be effectively sealed at the tray edges.
3. Tiles should extend at least to the corners of the tray and a minimum of 2.0 metres from the top of the tray.
FIXING KIT COMPONENTS, TOOLS REQUIRED, SITE
2
V8124
1X
V6113
X3
V8125
X4
V4111
X3
V2115
6X
V2114
X6
V6ST4 40
2
×
X
V4115
X4
V6M5 5
3
X
X
1
V6115
X
V6LP8076 L
X1
V6LP8076 R
X1
V6MLN05
X1
V8121
X1
V8122
X1
V8119
X1
V6S6SW05
X1
V8126
X1
V8127
X1
V8123
X1
V6S6SW07A
X1
V8118
X1
V4110
X3
V6M5 5
1
X
X
V1120
X1
V1121
X1
Horizontal rail
Vertical rail

MERLYN 6 Series Specifications

General

Glass Thickness	6 mm
Style	Modern
Warranty	Lifetime
Finish	Chrome
Type	Shower Enclosure
Material	Glass, Aluminium
Installation Type	Wall Mounted
