Merrychef MD0750 User Manual

Page 17 MD Series Ovens 32Z3329 Issue 6
Part number identification chart 1
No Description MD1400 MD1800
Pre Jan 2007
MD1800
From Jan 2007
Part No. Part No. Part No. Part No.
1
Outer Handle 30M0001 30M0001 30M0001 30M4002
2
Handle Bearing (4) 30M0002 30M0002 30M0002 30M0002
3
Inner Handle 30M0003 30M0003 30M0003 30M4003
4
Door Outer Skin 30M0004 30M0004 30M0004 30M0004
5
Glass Locator 30M0005 30M0005 30M0005 30M0005
6
Outer Door Glass 30M0006 30M0006 30M0006 30M0006
7
Door Body 30M0007 30M0007 30M0007 30M0007
8
Door Catch Bracket 30M0008 30M0008 30M0008 30M0008
9
Door Catch (2)// Catch hook 30M0009 30M0009 30M0009 30M4009
10
Door Catch Link Rod 30M0010 30M0010 30M0010 30M0010
11
Door Spring 30M0011 30M0011 30M0011 30M4011
12
Oven Cavity 30M0012 30M0036 30M0036 30M0036
13
Door Catch Crank 30M0013 30M0013 30M0013 30M0013
14
Upper / Lower Hinge Plate 30M0014 30M0014 30M0014 30M0014
15
Inner Door Film 30M0015 30M0015 30M0015 30M0015
16
Choke Cover 30M0016 30M0016 30M0016 30M0016
17
Control Panel Cover ( see note 1) 30M0017 30M0017 30M0017 30M0017
18
Membrane Blue 11M0384 11M0384 11M0384 11M0384
19
Display Screen 30M0019 30M0019 30M0019 30M0019
20
Control Housing Moulding 30M0020 30M0020 30M0020 30M0020
21
Logic PCB Assy 11M0326 11M0326 11M0326 11M0326
22
Housing Support Bracket 30M0022 30M0022 30M0022 30M0022
23
Relay PCB Assy 11M0327 11M0327 11M0327 11M0327
24
10 Way Ribbon Cable Assy 11E0081 11E0081 11E0081 11E0081
25
Insulating Sheet 30M0025 30M0025 30M0025 30M0025
26
Mains Cable Assy 31Z0220 31Z0220 31Z0220 31Z0220
27
Mica Plate and Stirrer Assembly 30M0027 30M0027 30M0027 30M0027
28
29
Decorative Trim LH 30M0029 30M0029 30M0029 30M0029
30
Decorative Trim Top 30M0030 30M0030 30M0030 30M0030
31
Air Inlet Filter 30M0031 30M0031 30M0031 30M0031
32
Chassis 30M0032 30M0032 30M0032 30M0032
33
HV Transformer J1342 30M0035 ———— ———— ————
HV Transformer J1338 ———— 30M0033 30M0033 30M0033
34
Decorative Trim RH 30M0034 30M0034 30M0034 30M0034
35
Strain Relief Bush 31Z1036 31Z1036 31Z1036 31Z1036
37
Lamp Cover Film 30M0037 30M0037 30M0037 30M0037
38
Lamp 30M0038 30M0038 30M0038 30M0038
39
Lamp Holder 30M0039 30M0039 30M0039 30M0039
40
Lamp Bracket 30M0040 30M0040 30M0040 30M0040
41
Air Outlet Duct 30M0041 30M0041 30M0041 30M0041
42
Temp Sensor 30M0042 30M0042 30M0042 30M0042
43
Thermal Fuse 30M0043 30M0043 30M0043 30M0043
MD1000
Note 1. Part 17 supplied as MD 1800, remove label for MD1000 & MD1400
