Page 21 MD Series Ovens 32Z3329 Issue 6
APPENDIX 2: Door interlock details
Models before January 2007, MD1000, MD1400 & MD1800
No Description Part No.
1 Outer Handle 30M0001
3 Inner Handle 30M0003
9 Door Catch (2) 30M0009
10 Door Catch Link Rod 30M0010
11 Door Spring 30M0011
13 Door Catch Crank 30M0013
65 Interlock/ Switch Holder 30M0065
66 a-d Microswitch V5S010CB 30Z1176
67 Fuse Cover 20Z1080
68 Spring 1 30M0068
69 Spring 2 30M0069
70 Top Lever 30M0070
71 Middle Lever 30M0071
72 Bottom Lever 30M0072
