Mesa/Boogie TriAxis User Manual

PAGE 2
FRONT PANEL: (Continued)
TO ACCESS PROGRAMS (via the numeric keys):
1. Press the SHIFT key one time to access the programs.
2. Select PROGRAM using nu-
meric keys located below GAIN,
TREBLE, MIDDLE, BASS, and
LEAD DRIVE windows.
3. Press the ENTR key one time
to access new PROGRAM number
and audition the PRESET listed at
that location.
TO ACCESS PRESETS (via the numeric keys):
1. Press the SHIFT key two times to make PRESET the active window,
then select the new PRESET using the numeric keys once
again.
2. Press the ENTR key one time to lis-
ten to the displayed flashing PRESET.
3. Press the ENTR key two times to
write displayed flashing PRESET to
displayed PROGRAM number.
MAPPING A PRESET TO A PROGRAM:
First understand that PRESETS are “SOUNDS” and that PROGRAMS are “Midi
PROGRAM LOCATIONS.”
1. Call up the PROGRAM LOCATION number that you
wish to write using the left & right arrowed keys directly
under the PROGRAM / CHANNEL window, a Midi Control-
ler, or by using the numeric keys located directly under
the GAIN thru LEAD 1 DRIVE keys.
2. Choose the desired PRESET “sound” you wish to list
under the Program Location number using the left & right arrowed keys directly under the PRESET window. Now you should see the
PRESET you wish to map in the PRESET window and the Program Number you wish to write this PRESET under, in the PROGRAM
/ CHANNEL window.
3. Press the ENTR key two times. Procedure is now complete.
TREBLEGAINPROGRAM/CHANNELPRESET
PGM
/CH
COPY
01 23
ENTR
FLASH
SHIFT
OOGIE
B
M
ESA
ALL TUBE PREAMPLIFIER
TREBLEGAINPROGRAM/CHANNELPRESET
PGM
/CH
COPY
01 23
ENTR
FLASH
TREBLEGAINPROGRAM/CHANNELPRESET
PGM
/CH
EXIT
COPY
01 23
PRESET
NUMBER
PROGRAM
NUMBER
ENTR
SHIFT
OOGIE
B
M
ESA
ALL TUBE PREAMPLIFIER

Mesa/Boogie TriAxis Specifications

General

Type	Tube Preamp
MIDI Control	Yes
Tubes	5 x 12AX7
Inputs	1 x Instrument
Effects Loop	Yes
Footswitchable	Yes
Outputs	2 x 1/4" (Main), 1 x 1/4" (Recording)
