Page #25 background imageLoading...
Page #25 background image
25
ENGLISH
Make several passes at less
depth of cut.
Feed rate too little (thicknessing)
Resin buildup on thicknesser bed
Clean thicknesser bed and apply
light coat of anti-seize compound.
Feed rollers stiff
Repair feed rollers.
Drive belt slips
Re-tension drive belt
Work piece jams
(thicknessing)
Too much material removed in one
pass
Make several passes at less
depth of cut.
11. Technical Specifications
HC 260 C
WNB
HC 260 C
DNB
Motor 50 Hz W 2200 2800
Voltage V230 400
Fuse protection A 16 16
Protection class IP 54 54
No-load speed
motor
Cutterblock
min
-1
min
-1
2800
6500
2700
6500
Feed rate, thickness planing m/min 5 5
Planer knife dimensions
length
width
thickness
mm
mm
mm
260
18.6
1
260
18.6
1
Machine dimensions
length (overall across infeed and outfeed table)
width
height
mm
mm
mm
1110
575
940
1110
575
940
Weight
Machine in packing
Machine ready to work
kg
kg
76.0
71.0
76.0
71.0
Workplace-related emission value according to DIN 45635*
Operating noise when jointing dB (A) 108.2 108.2
Sound power level according to DIN 45635*
Operating noise when jointing dB (A) 100.8 100.8
Work piece dimensions
max. width
max. height (thickness planing)
mm
mm
260
160
260
160
* The values mentioned here state how much noise is emitted from the machine (= emission value). How much of this noise
reaches the operator's ear (= immission value) can not be shown here, as this depends on the particular ambient conditions. It
makes sense, however, to use hearing protection even though the values stated here do not necessarily indicate a need for this.

Table of Contents

Other manuals for Metabo HC 260 C

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Metabo HC 260 C and is the answer not in the manual?

Metabo HC 260 C Specifications

General IconGeneral
Planing Width260 mm
Max. Planing Depth3 mm
Max. Thicknessing Height160 mm
Feed Rate5 m/min
Motor Power2.2 kW
Chip removal thickness planing3 mm
Chip removal thickness thicknessing3 mm
Table thicknessing table400 x 260 mm
Passage height/width160 mm / 260 mm
Planing shaft diameter63 mm
Number of blades2
Planing table260 mm
Planing shaft speed6, 500 rpm
