22
Display
formats menu
Description
Display Res for Inch Press Enter to specify the Display Resolution for Inch Units.
Display Res for MM Press Enter to specify the Display Resolution for MM Units.
Display Res for DMS
Press Enter to specify the Display Resolution for Degrees Minutes
Seconds(DMS) Units of measurement results.
Display Res for DD
Press Enter to specify the Display Resolution for Decimal Degrees(DD) Units
of measurement results.
Display Res for Q
Axis DMS
Press Enter to specify the Display Resolution for Degrees Minutes
Seconds(DMS) Units for connected Q encoders.
Display Res for Q
Axis DD
Press Enter to specify the Display Resolution for Decimal Degrees(DD) Units
for connected Q encoders.
Q Display Range
Press Enter to select Q Axis angle display format. Use softkey 1 or softkey 2 to
select the desired output format.
+/- 180 deg or 0-360 display mode
