To enable the xLogic function, highlight the menu items and press the softkey menu item labelled “Yes”.
4.4 Printouts
The “Printouts” settings screen contains settings that format the report view printout that is generated
from the Mx200 Print function.
Report Title
• Select the “Report Title” menu item and press “Enter”. An alpha-numeric entry dialog and
keyboard will be displayed. Enter the desired new report title and press “Ok” to confirm. This
new report title will be displayed in the header for all report printouts.
Include Date and Time
• Select the “Include Date and Time” menu item. Set to Yes or No using the softkeys to include or
hide the date and time stamp from the report header.
4.5 Programs
The “Programs” settings screen contains settings that impact program playback in the Mx200.
User Recorded Edge Mode
Part programs in the Mx200 will automatically select the Manual Edge Probe for the first feature of
playback. This is done as a convenience to help prevent unintentional entering of edge positions, while
positioning your sensor to begin playback.
Note: Throughout program playback the current probe can always be changed by selecting it from the
probe menu.
• To prevent the Mx200 from setting the startup probe, and to instead always use the recorded
probe type, set the “User Recorded Edge Mode” setting to “Yes”
