1.2 Mx200 Specifications
Display: 7" Color 1024 X 600 LCD, with an LED backlit capacitive touch screen.
Power: Power supply(included): 100-240VAC, 50/60Hz, 3.0A. Power Input to Mx200: 12V.
Agency Approvals: CE
DRO Dimensions: 286mm wide x 51mm deep x 162 mm high
DRO Baseplate Dimensions: 120mm wide x 125mm deep x 9.5mm high
Mounting Options:
OEM mount: Two Riser Blocks providing up to 4 distinct viewing angles, using (2) M6 threaded holes,
spaced 38mm.
RAM ball mount: One Riser Block with 1.5” RAM Ball.
Base plate: Base Plate with two Riser Blocks providing up to 4 distinct viewing angles from the base.
1.3 Hardware Installation and Connections
The following section describes how to connect;
Mounting hardware(A)
Power Connection(B)
Encoder Connections(C)
Optical Edge Cabling(D)
