36
Send Units
Specifies whether or not the unit type for a given value is sent along
with the value. Set to Yes or No using the appropriate softkey.
Send Eol(End of Line)
Configures the desired character to be sent at the end of an output
line. CR(Carriage Return), Line Feed(LF) or CR &LF can be selected
using the appropriate softkey. EOL can also be set to None.
Field Delimiter
Configures the desired field delimiter(separator) to Comma or Tab.
Set to desired delimiter using the appropriate softkey.
MLX200 9 Pin
Dsub(F)
Description
Switch Device(Footswitch/Buttons/ETC)
RS232 9 Pin
Dsub(M)
1
TRIG_2_IN
SW2 Common
NC
2
RX_IN
2
3
TX_OUT
3
4
TRIG_1_OUT
NC
5
GND
SW1 & SW2 (Normally Open) & Earth
Ground
5
6
TRIG_1_IN
SW1 Common
NC
7
TRIG_3_IN
NC
8
TRIG_2_OUT
NC
9
TRIG_3_OUT
NC
4.8 Sounds
The “Sound” settings screen contains setup parameter for the Mx200’s internal beeper mechanism.
Sound
Function
Description
Enable Sound
Set to Yes or No using the corresponding sofkey to enable or disable the
Mx200 beep sound.
