95-9313B
7
Sub-dash airbox modifications
3. Remove the upper actuator arm
from the passenger vent door.
Remove the lower actuator arm
from the vent doors. Unclip the
passenger side first and then the
drivers side. (Figure C)
4. Remove the passenger side vent
door. Unclip from the bottom, then
push and rotate the top clip out of
the slot in the airbox. (Figure D)
Note: Remember the orientation
of the vent door arm (approx.
11:00) when removing to ease in
reinstallation.
Continued on the next page
(Figure C)
(Figure D)
