Metra Electronics 99-3305 - Dash Disassembly - Buick Lucerne, Chevy Impala;Monte Carlo; Remove Trim Panel; Remove Radio and A;C Control

99-3305 DASH DISASSEMBLY
BUICK LUCERNE
CHEVY IMPALA / MONTE CARLO 2006-09
A
B
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the trim panel
around radio and a/c control.
(Figure A)
2
Remove (6) 9/32” screws to extract
radio and a/c control from sub dash.
(Figure B)
3
Continue to kit assembly.
