99-3305 DASH DISASSEMBLY
A
HUMMER H2 2008-09
Unclip the radio trim panel including
the a/c vents. Unplug any harnesses
connected to the panel and remove the
panel.
(Figure A)
2
Remove (4) 9/32” screws securing the
climate controls. Unplug and remove
the climate controls.
3
Remove (4) 9/32 screws securing the
radio. Unplug and remove the radio.
4
Continue to kit assembly.
* Note: Refer also to the instructions included with the aftermarket radio.
Disconnect the negative battery termi-
nal to prevent an accidental short cir-
cuit.
1
