3
99-3305 DASH DISASSEMBLY
CHEVY EXPRESS VAN 2008-09/GMC SAVANNA 2008-09
Remove (2)10mm bolts from below knee bolster under steering column and remove
panel.
2
Remove (2)10mm bolts from panel below passenger dash airbag and remove panel.
3
Unsnap and remove radio and instrument cluster panel. (May not be necessary to
completely remove radio and instrument cluster panel to access radio.)
4
Remove (4) 9/32” bolts to remove radio.
5
Continue to kit assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
Disconnect the negative battery terminal to prevent an accidental short circuit.
1
