Metra Electronics 99-3306 - Kit Assembly; DIN Mount Radio Provision with Pocket

99-3306 KIT ASSEMBLY
2
A
B
C
DIN MOUNT RADIO PROVISION WITH POCKET
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking outward. (Figure A)
1
Slide the aftermarket radio into the DIN
cage until it snaps into place. (Figure B)
2
Snap the pocket into the radio housing.
(Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
