99-3306 KIT ASSEMBLY
5
STACKED ISO UNITS PROVISION
Cut and remove the center bar from
the radio housing.
(Figure A)
1
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
2
Slide the stacked ISO units into the
bracket/radio housing assembly and
secure the units to the assembly using
the screws supplied with the units.
(Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
C
D
Snap the Double DIN trim-plate onto
the front of the housing/radio assem-
bly.
(Figure D)
4
