99-3528
DASH DISASSEMBLY (cont’d)
2004-2006 PONTIAC GTO
Remove (2) Phillips screws exposed
at the bottom of the center panel
surrounding radio and remove panel.
(Figure E)
6
E
Unclip and remove trim panel sur-
rounding radio and A/C controls.
7
Remove (3) Phillips screws holding
"cage" in radio opening.
(Figure F)
8
Pull down on the "cage" from the
opening inside on the top and
remove.
(Figure G)
9
F
G
