2
19
Disconnect the negative battery terminal to
prevent an accidental short circuit. Using
Metra's 86-5618, pull the factory head unit
from the dash and disconnect the wiring.
Disconnect the negative battery terminal to
prevent an accidental short circuit. Remove
(2) screws from the top edge of the dash trim
bezel. Pull out on the top of the bezel,
unhook the base and remove the bezel. If a
factory head unit is NOT present, scribe the
(4) mounting holes and radio opening onto
the bezel. Drill the holes, cut the opening
and place (4) U-clips over the mounting
positions.
1
1
FORD Aspire 1994-97
FORD Bronco / Pickup 1980-86
2
2
Cut and remove all mounting tabs on Radio
Housing #1 EXCEPT tabs "B". The
mounting tabs can be identified by the
stamped letter on the back of each tab. Skip
to the Installation Instructions for ALL
VEHICLES on Page #21.
Disconnect the negative battery terminal to
prevent an accidental short circuit. Remove
the ashtray and (2) screws from the ashtray
cavity. Using Metra's 86-5618, pull the
factory head unit from the dash and
disconnect the wiring.
1
MAZDA Protege 1995-00
2
Disconnect the negative battery terminal to
prevent an accidental short circuit. Using
Metra's 86-5618, pull the factory head unit
from the dash and disconnect the wiring.
1
MERCURY Capri XR2 1991-94
2
Cut and remove the shaft supports from the
Faceplate. Skip to step #3c in the
Installation Instructions for ALL VEHICLES
on Page #22.
Cut and remove the shaft supports from the
Faceplate. Skip to step #3c in the
Installation Instructions for ALL VEHICLES
on Page #22.
Cut and remove the shaft supports from the
Faceplate. Skip to step #3c in the
Installation Instructions for ALL VEHICLES
on Page #22.
"B"
"B"
