1. Using the 86-5618 removal keys pull
the factory radio/climate control panel
from the dash. (Figure A)
2. Disconnect the vacuum hose harness
and connectors from the audio system,
blower motor switch, A/C dampener
door switch, and potentiometer.
3. Remove the panel.
Continued to kit preparation
3
Ford Taurus/Mercury Sabel
2000-2003
Dash Disassembly 99-5716
(Figure A)
To Next Page
