4
Kit Preparation 99-5716
Ford Taurus/Mercury Sabel
2000-2003
1. Turn the factory climate control dials
into a vertical position and pull the dials
off. (Figure A)
2. Remove (2) 5/16” hex head screws
securing the temperature/fan control
switches and remove switches. Unclip
the climate control switch and remove.
(Figure B)
3. Mount switches to the back of the
integrated mounting kit with the (2)
supplied #8 x 3/8” Phillips pan head
screws. (Figure C)
4. Holding the climate control dials in a
vertical position insert the dials onto
the posts of the mounted switches and
secure. (Figure D)
Continue on next page
(Figure B)
(Figure D)
(Figure C)
(Figure A)
To Next Page
