Kit Assembly 99-5716
1. Snap the ISO Faceplate into the
radio opening. (Figure A)
2. Attach the ISO Brackets to the inner lip
of the radio opening. (Figure A)
3. Slide the head unit into the radio
opening, align the holes in the head unit
with the holes in the ISO Brackets and
mount the unit to the brackets with the
screws supplied with the unit.
(Figure A)
3. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
4. Reassemble dash in reverse order
of disassembly. (Figure B)
ISO head unit provision
(Figure A)
(Figure B)
