Metra Electronics 99-5814 - Single DIN Radio Installation with Pocket

1. Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs outward. (Figure A)
2. Slide the aftermarket radio into the
DIN cage and until it snaps into place.
(Figure B)
3. Snap the pocket into the radio housing.
(Figure C)
Reassemble dash in reverse order of
disassembly.
DIN Mount Radio Provision
With Pocket
(Figure A)
(Figure B)
(Figure C)
4
99-5814
