Metra Electronics 99-5814 - Double DIN Radio Installation

6
99-5814
1. Cut and remove the center bar from the
radio housing. (Figure A)
2. Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
3. Slide the Double DIN radio into the DDIN
bracket/radio housing assembly and
secure the radio to the assembly using
the screws supplied with the radio.
(Figure C)
3. Snap the Double DIN trim plate onto the
front of the radio/housing assembly.
(Figure C)
Reassemble dash in reverse order of
disassembly.
Double DIN Radio Provision
(Figure A)
(Figure B)
(Figure C)
