99-5814
3
1. Attach the climate control to the radio
housing using the factory hardware
removed in step 7 of dash disassembly.
(Figure A)
Note: There are (2) extra radio housing
panel clips included with the kit in case
removal of the kit is necessary at any
time. (Figure B)
Continue to kit assembly
Kit Preparation
(Figure A)
TWO EXTRA
RADIO HOUSING
RETAINING CLIPS
(Figure B)
To Next Page
